Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 50 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range50–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50
The AirTAC SDAJ32X100-50 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M10x1.25) screw, you shorten the forward stroke on-site across a 50 to 100 mm window without swapping shims or parts. The retract motion remains full length.
Its short riveted body saves axial mounting depth where round-body or profile units will not fit. End-of-travel deceleration relies on a fixed NBR bumper, which is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot host reed or electronic switches; specify the -S variant if sensing is required.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 50 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 50 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -50 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 Is Used
Trial Positioning Jigs
Dial in the extend stop between 50 and 100 mm to find the exact contact point for prototype parts before locking down the sequence.
Changeover-Heavy Lines
Quickly reset the mechanical stop for different product lengths using the M10x1.25 adjuster, avoiding the need to swap out entire cylinders.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 the Right Cylinder?
When sizing pneumatics, evaluate neighbouring bores against your exact load.
Operators who require frequent on-machine stroke tuning during setup-heavy changeovers will benefit from the 50 mm adjustment window. Confirm your parameters: 32 mm bore, 100 mm max stroke, 50 mm window, PT1/8 port, female M6x1.0 rod thread, and no magnet. Remember that a plain SDAJ does not hold position upon air loss or valve centring; the fixed bumper only decelerates near the end. For secure load holding without live pressure, integrate an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 50–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50 FAQ
The theoretical maximum push is 82 kgf at 1.0 MPa.
This screw acts strictly as a mechanical stop, not a mid-stroke lock, and the cylinder cannot hold a load if air pressure is lost.
