Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50S
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
AirTAC SDAJ32X100-50S Adjustable Compact Cylinder Specifications
- Series: SDAJ Ultra-Slim Cylinder Series
- Model: SDAJ32X100-50S
- Bore size: 32mm (Available in 32/40mm series)
- Stroke: 100mm (Customizable: 10-300mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard SW32-50S bracket included
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal type: NBR seals with wear-resistant ring
- Weight: 1.45kg (with accessories)
- Dimensions:
- Body length: 160mm (excluding rod)
- Width: 50mm (mounting surface)
- Height: 52mm (compact profile design)
- ISO standard: Compliant with ISO 6432
- Protection class: IP54 (standard sealing)
Ultra-slim cylinder featuring space-saving 52mm height profile with dual-action operation. Incorporates precision-machined guide mechanism for minimal lateral play (±0.2mm). The adjustable cushioning system allows impact force optimization through 270° rotary valve adjustment. Pre-lubricated for maintenance-free operation in clean environments.
- High-density automation cells (electronics assembly)
- Vertical lift mechanisms in packaging lines
- Medical device positioning systems
- Robotic end-effector tooling
- Semiconductor wafer handling
Installation tip:
Maintain 0.5-1mm clearance between mounting surfaces for thermal expansion.
Use C-shaped spanner for cushion adjustment (torque ≤1.5N·m). Lubricate with ISO VG32 hydraulic oil if used in high-cycle applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | SDAJ32X100-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
