Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range25–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S
The AirTAC SDAJ32X100-75S is a double-acting compact cylinder featuring an external adjustable extend stop. By turning the R (M10x1.25) screw, you can dial the extend stroke down by up to 75 mm, yielding a usable range of 25 to 100 mm directly on the machine without changing parts.
Its short riveted body minimizes axial mounting depth where a longer cylinder would not fit, while the built-in magnet (-S) supports AirTAC reed or electronic solid-state switches for position sensing. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 25 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -75 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S Is Used
Machining Center Clamps
Dial in the 25-100 mm extend stop during part changeovers to clamp raw billets of varying widths without swapping out cylinder hardware.
Lab Test Fixtures
Use the fine-tuning capability to probe delicate samples at exact extensions, ensuring the NBR bumper absorbs the final impact without crushing the specimen.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S the Right Cylinder?
Choose this specific model if your fixture requires frequent on-site stroke tuning or trial positioning.
Verify your parameters: 32 mm bore, 100 mm maximum stroke, 75 mm adjust window, PT1/8 port, female M6x1.0 rod thread, and the included magnetic piston. Remember that a standard cylinder does not hold a load when air is lost or the valve is centered; the fixed bumper only decelerates near the end of travel. For load holding without live pressure, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 25–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75S FAQ
The theoretical maximum push is 82 kgf at 1.0 MPa.
The R (M10x1.25) screw shortens the extend stroke by up to 75 mm, allowing a usable range of 25 to 100 mm. The -S option includes a built-in piston magnet compatible with AirTAC reed or electronic switches for position sensing.
