AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB

The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.

  • BoreØ32 mm
  • Max stroke100 mm
  • Adjustable range25–100 mm
  • Adjuster threadM10×1.25
  • Port sizePT1/8
  • CushionFixed NBR bumper (both ends)
$72.55 $80.05Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SDAJ32 stroke, mounting and version on one page All SDAJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB

The AirTAC SDAJ32X100-75SB is a compact double-acting double-rod cylinder engineered for on-site extend length tuning. An external R (M10x1.25) adjustment screw dials the forward stop down from the 100mm maximum to anywhere within the 25-100mm window, eliminating the need for shims or part swaps during commissioning.

This variant includes a built-in piston magnet (-S) for direct mounting of AirTAC reed or electronic switches, alongside a male-threaded piston rod (-B, M10x1.25) for secure external tooling attachment. The short riveted body conserves axial mounting depth where space is tight. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB Technical Specifications

ModelAirtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ32 mm
Max stroke100 mm
Adjustable range25 – 100 mm
Adjuster thread (R)M10×1.25
Port sizePT1/8
Acting typeDouble acting
Rod end threadM6×1.0 F / M10×1.25 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB

SDAJCompact double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Maximum stroke length in mm.
-75Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB Is Used

straighten

Variable Length Gauging

Dial the extend stop from 25 to 100mm to inspect or sort parts of varying dimensions on a single fixture without swapping out physical hard stops.

science

Prototype Positioning

Sweep through multiple extend distances during trial runs to find the exact kinematic contact point, locking the M10x1.25 adjuster screw once the ideal position is found.

Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB the Right Cylinder?

When sizing this 32mm bore, evaluate your thrust requirements bidirectionally.

Opt for this specific model if your fixture requires frequent changeovers or trial positioning across a wide 75mm adjustment band. Verify your setup requires the male M10x1.25 rod end and PT1/8 porting. Remember that a standard cylinder drifts when air is lost or the valve is centered; the fixed bumper only decelerates the stroke end and does not lock the load. For suspended loads, integrate an external rod lock or pilot-operated check valve.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 25–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M10×1.25 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75SB FAQ

The theoretical maximum output is 82 kgf at 1.0 MPa. It operates between 0.15 and 1.0 MPa, with a proof pressure of 1.5 MPa, and runs at speeds of 30-500 mm/s.

Turning the R (M10x1.25) screw mechanically shortens the extend stroke by up to 75mm, providing a usable forward range of 25-100mm while retract remains full. The included -S piston magnet allows you to mount AirTAC reed or electronic solid-state switches directly into the body sensor grooves for position signaling.
