Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-20B
$88.37
Regular price
$95.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-20B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation Tip:
When using stroke adjustment screws, reduce operating pressure below 0.7MPa. Apply thread-locking compound to adjustment screws after final positioning. For vertical mounting, install exhaust mist lubricator upstream.
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-20B Adjustable Ultra-Thin Cylinder Specifications
- Model Series: SDAJ50~63
- Full Model: SDAJ50X100-20B
- Bore Size: 50mm
- Stroke: 100mm (adjustable through external stopper)
- Mounting Type: Standard ISO 15552 foot mounting (20B suffix)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Fixed rubber buffer + adjustable end-position throttle
- Port Size: M5x0.8 (standard), optional G1/8
- Piston Rod Thread: M10x1.25
- Material: Aluminum alloy barrel, hardened chromium-plated piston rod
- Seals: NBR/Urethane hybrid seals (low friction design)
- Repeat Positioning Accuracy: ±0.5mm
- Max Speed: 500mm/s (with cushioning)
- Weight: 1.8kg (excluding accessories)
- Dimensions:
- Total Length (L): 190mm (at mid-stroke)
- Body Width (W): 63mm
- Height (H): 50mm (mounting surface to top)
Ultra-compact profile cylinder (40% thinner than standard models) with precision stroke adjustment via hex wrench. Features dual anti-rotation guide rods for enhanced lateral load capacity. Pre-lubricated for maintenance-free operation up to 3,000km travel distance. Compatible with magnetic sensors for position feedback (sensor groove integrated).
Typical Applications:
- High-density robotic gripper arrays in electronics assembly
- Precision positioning in semiconductor wafer handling
- Vertical space-constrained presses
- Medical device actuation requiring smooth movement
- Packaging machine ejector mechanisms
Installation Tip:
When using stroke adjustment screws, reduce operating pressure below 0.7MPa. Apply thread-locking compound to adjustment screws after final positioning. For vertical mounting, install exhaust mist lubricator upstream.
Maintenance Note:
Relubrication interval extends to 5 million cycles when using ISO VG32 turbine-grade air compressor oil. Avoid silicone-based lubricants to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-20B |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
