The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30B is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 70 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-30B is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M16x1.5) screw, you can dial the outward stroke down from the 100mm maximum to 70mm directly on the machine, avoiding shims or part swaps.
This specific SKU includes a male M18x1.5 piston rod thread (option B) and lacks a piston magnet, meaning it cannot host reed or electronic switches without the -S variant. The short riveted body saves axial mounting depth where round-body or profile cylinders will not fit. End shock is handled solely by a fixed NBR bumper, which decelerates the stroke end but is not an adjustable air cushion.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 70 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -30 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Tune the outward reach on-site to accommodate varying box heights, relying on the fixed NBR bumper to absorb the end shock.
Stepping down, the SDAJ40 provides 628.3N at the same pressure; stepping up, the SDAJ63 offers 1558.6N. Verify your requirements for bore, 100mm max stroke, 30mm window, PT1/4 port, male M18x1.5 rod, and no magnet. Note that a plain cylinder does not hold its load on air loss or valve centering—the piston drifts and the fixed bumper only decelerates near the end. For a held load, specify an external rod lock or a pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
The theoretical maximum push is 200kgf at 1.0MPa.
The R (M16x1.5) screw shortens the extend stop by up to 30mm, yielding a usable 70-100mm range. It is a mechanical stop, not a mid-stroke lock; the cylinder cannot hold a load without live air pressure.
