AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 60 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range60–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$88.37 $95.87Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40

The AirTAC SDAJ50X100-40 is a compact double-acting double-rod cylinder featuring an external M16x1.5 adjuster screw that dials the extend stop directly on your machine. You can tune the forward stroke anywhere between 60 and 100 mm without swapping shims or parts, while the retract motion remains full length.

A short riveted body minimizes axial mounting depth where space is tight. End-of-travel deceleration relies on a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot host reed or electronic switches; adding an -S variant is required for position sensing.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40 Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range60 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 40 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-40Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40 Is Used

precision_manufacturing

Tooling Changeover

Dial the extend stop from 60 to 100 mm during machine setup to accommodate different fixture heights without machining new spacers.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40 the Right Cylinder?

Stepping down to the SDAJ40 yields 628.3 N, whereas stepping up to the SDAJ63 provides 1558.6 N.

This model suits applications requiring frequent on-site stroke tuning or changeovers. Confirm the 50 mm bore, 100 mm maximum stroke, 40 mm adjustment window, and PT1/4 port. It has a female M10x1.5 rod thread and no magnet. Remember that a standard cylinder does not hold a load if air pressure drops or the valve centers; the piston drifts and the fixed bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 60–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40 FAQ

At 0.7 MPa, push is 1374.4 N and pull is 1154.5 N. The theoretical maximum push is 200 kgf at 1.0 MPa.

Turning the M16x1.5 screw shortens the extend stroke by up to 40 mm, allowing on-machine tuning between 60 and 100 mm. The screw acts only as a mechanical stop and does not alter force. It is not a lock; the cylinder cannot hold a load if air is lost, requiring an external rod lock for holding.
