The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40B is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 60 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-40B is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the M16x1.5 adjuster screw, you can set the extend position anywhere between 60 and 100 mm directly on the machine.
This variant features a male M18x1.5 piston rod thread and includes no piston magnet. The short riveted body saves valuable axial mounting depth where a larger profile cylinder will not fit. End-of-stroke deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 60 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 40 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -40 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the 60-100 mm extend stop during initial commissioning to perfectly position a 50 kg part transfer arm without machining new spacers.
Choose this 50 mm bore if your application requires that middle-ground force output along with on-site stroke tuning.
Confirm your requirements for a 100 mm maximum stroke with a 40 mm adjustment window, a PT1/4 air port, and the male M18x1.5 rod thread designated by the B option. Note that this specific SKU lacks the S magnet option, so it cannot support reed or electronic switches. Furthermore, a plain cylinder does not hold a load if air pressure is lost or the valve is centred; for vertical load holding without live pressure, install an external rod lock or pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
This 50 mm bore cylinder has a PT1/4 air port.
The external M16x1.5 screw mechanically shortens the extend stroke from the 100 mm maximum down to 60 mm without altering the force. It is strictly a stop, not a mid-stroke lock; the cylinder will drift if air is lost, so use a pilot-operated check valve for load holding.
Genuine AirTAC parts produced by AirTAC factory.
Covers non-human-caused product damage.
Most standard models are dispatched in 3-5 days.
Most inquiries answered within 7 hours.
Send us the quantity and destination. We confirm price, availability and lead time — usually within 7 hours.
