The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-75 is a double-acting compact cylinder featuring an external M16x1.5 adjuster screw that dials the extend stop directly on your machine. You can set the outward travel anywhere between 25 and 100 mm without swapping shims or parts, making it ideal for trial positioning and frequent format changes. Retract travel remains full length.
The short riveted body saves valuable axial mounting depth where larger profile units fail to fit. End shock is managed solely by a fixed NBR bumper, so consider an external shock absorber for high-energy cycles.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 25 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -75 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Adjust the mechanical stop on the fly for different box heights, using the fixed NBR bumper to absorb the end shock across repetitive sealing cycles.
This configuration specifies a 100 mm maximum stroke with a 75 mm adjustment window, a PT1/4 port, and a female M10x1.5 rod end. Note that this specific SKU lacks a piston magnet, so it cannot accept reed or electronic switches. Furthermore, the fixed NBR bumper only decelerates the stroke end; a plain cylinder does not hold position on air loss. For suspended loads, specify an external rod lock or pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
Turning the external M16x1.5 screw shortens the extend stroke by up to 75 mm, allowing usable outward travel between 25 and 100 mm. This SKU ships without a piston magnet; you must select the -S variant to use reed or electronic switches.
