AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range25–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$88.37 $95.87Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B

The AirTAC SDAJ50X100-75B is a compact double-acting double-rod cylinder built for on-site extend positioning. An external M16x1.5 adjuster screw lets you dial the outward stop anywhere from 25 to 100 mm without swapping shims or parts.

The short riveted body drastically cuts axial mounting depth where a larger profile cylinder will not fit. This specific SKU features a male M18x1.5 piston rod thread and lacks a piston magnet, meaning it cannot host reed or solid-state switches. End-of-travel deceleration is handled strictly by a fixed NBR bumper, which absorbs shock but does not function as an adjustable air cushion or a mid-stroke lock.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range25 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-75Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B Is Used

precision_manufacturing

Adjustable Press Tooling

Dial the extend stop from 25 to 100 mm via the M16x1.5 screw to accommodate varying material thicknesses on the same press line without machining new spacers.

vertical_align_center

Vertical Lift Stops

Set precise upper travel limits for lifting platforms; remember to add an external pilot-operated check valve, as the fixed NBR bumper decelerates but does not lock the load.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B the Right Cylinder?

Choose this model when your setup requires precise extend-end tuning during frequent product changeovers.

Confirm your parameters: 50 mm bore, 100 mm maximum stroke with a 75 mm adjustment window, PT1/4 air port, and a male M18x1.5 rod end. Note that a plain SDAJ cannot hold a load if air pressure drops or the valve centers—the piston will drift. For suspended or vertical loads requiring fail-safe holding, integrate an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 25–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75B FAQ

The theoretical maximum push is 200 kgf at 1.0 MPa.

Turning the external M16x1.5 screw shortens the extend stroke by up to 75 mm, allowing on-machine tuning between 25 and 100 mm. This specific SKU lacks the -S magnet, so it cannot accept reed or electronic switches; you would need the -S variant for position sensing.
