AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR10006JN

Genuine AirTAC piston pressure regulator, order code SDR10006JN from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR100 · PT1/8
  • Type and bracketStandard, no bracket (J)
  • Pressure gaugeNo gauge (N)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$15.32 $22.82Save 32%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR10006JN

The SDR10006JN is the most stripped-down PT1/8 configuration of the AirTAC SDR100 piston pressure regulator: code J deletes the mounting bracket and code N deletes the pressure gauge, leaving a bare compact regulator body for 1/8 PT pipework. Regulation remains the standard 0.05-0.9 MPa range, with 1.0 MPa (145 psi) maximum pressure, 1.5 MPa (215 psi) proof pressure and operation from -20 to +70 C.

This piston back-pressure type stays true to the series character: a simple, small and cost-effective unit that is easy to install, with stable output pressure for circuits that do not demand high regulating accuracy. Because no gauge is fitted, pressure is read on a separate instrument elsewhere in the circuit, which keeps the regulator footprint minimal and the visible hardware clean.

Airtac SDR Pressure Regulator SDR10006JN Technical Specifications

Order codeSDR10006JN
ProductPiston Pressure Regulator
Model and portSDR100 · PT1/8
Type and bracketStandard, no bracket (J)
Pressure gaugeNo gauge (N)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

Take SDR10006JN when your panel already displays circuit pressure on its own gauges or a sensor, so the built-in gauge would be redundant and code N saves it. If you want an at-the-valve MPa readout, step up to SDR10006J1, and to SDR100061 if the mounting bracket is also wanted; the JN code drops both. The port alternatives on the SDR100 size are M5 (SDR100M5...) and the 1/4 port sits in the SDR200 series. Keep this standard type for setpoints anywhere in 0.05-0.9 MPa; only if pressure never rises above 0.4 MPa is the low-pressure L code with its 0.03-0.4 MPa band the better match, and G or T thread codes switch the gauge scale to bar or psi on the versions that carry a gauge.

Applications

inventory_2

OEM machine builds at volume

A lean 1/8 PT regulator for original equipment builders whose control panels carry their own pressure indication, so the N and J codes remove the gauge and bracket they would never use.

sensors

Sensor-monitored pressure zones

Pairs with an electronic pressure sensor in the circuit for monitoring, while the regulator itself holds the 0.05-0.9 MPa setpoint within the 1.0 MPa maximum envelope.

build

Space-critical sub-plate mounting

The bracketless, gaugeless body occupies minimal space behind a machine panel or on a crowded manifold, operating from -20 to +70 C on standard compressed air.

FAQ

What are the essential numbers for the SDR10006JN?

SDR100 piston back-pressure regulator, PT1/8 port (code 06), standard regulating range 0.05-0.9 MPa, maximum pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, no gauge (code N), no mounting bracket (code J), fluid air.

How do I set pressure on the SDR10006JN without a gauge?

The gauge is intentionally omitted (code N), so set and verify the pressure with an instrument elsewhere in the circuit, such as a panel gauge or sensor; the datasheet gives no built-in indication for this code. If you prefer direct reading on the body, SDR10006J1 adds an MPa-scale gauge while keeping the same bracketless 1/8 PT layout.
