AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR10006LJN

Genuine AirTAC piston pressure regulator, order code SDR10006LJN from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR100 · PT1/8
  • Type and bracketLow-pressure (L), no bracket (J)
  • Pressure gaugeNo gauge (N)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$15.32 $22.82Save 32%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR10006LJN

The AirTAC SDR10006LJN is the leanest PT1/8 SDR100 build: low-pressure L type, J bracket omitted, and N leaving the pressure gauge off. You get the bare piston back-pressure regulator only, which suits panels that already carry their own instrumented readout or feed a downstream gauge elsewhere in the circuit.

Stripping the gauge and bracket lowers the fitted footprint while keeping the SDR100 strengths: small, simple and cost-effective back-pressure regulation in the 0.03-0.4 MPa L band. Pressure limits are unchanged at 1.0 MPa maximum with 1.5 MPa proof, over a -20 to +70 C fluid range.

Airtac SDR Pressure Regulator SDR10006LJN Technical Specifications

Order codeSDR10006LJN
ProductPiston Pressure Regulator
Model and portSDR100 · PT1/8
Type and bracketLow-pressure (L), no bracket (J)
Pressure gaugeNo gauge (N)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

Order SDR10006LJN when your machine already displays circuit pressure and you want the smallest PT1/8 low-pressure SDR100. Add the gauge back by ordering SDR10006LJ1, or both gauge and bracket with SDR10006L1. If setpoints rise above 0.4 MPa, switch to the standard-band SDR10006JN, and step up to SDR200 series codes for the 1/4 port.

Applications

sensors

Instrumented test benches

Feeds bench circuits that read pressure from their own transducers, so the regulator itself needs no gauge and the N code keeps the body minimal.

factory

Dense multi-drop lines

Installed in rows on production machines where every drop already has a gauge, saving panel width by omitting the SDR100 gauge and bracket per J and N.

valve

Secondary low-pressure feeds

Serves as a set-and-forget reduced-pressure feed under 0.4 MPa to pilot lines or low-pressure valves that are monitored elsewhere.

FAQ

What are the key specifications of the SDR10006LJN?

PT1/8 port, SDR100 piston back-pressure regulator, low-pressure L range 0.03-0.4 MPa, no gauge (code N) and no bracket (code J), max operating pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), fluid air, temperature -20 to +70 C.

How do I read the output pressure if this code has no gauge?

The N option omits the regulator gauge entirely, so monitor pressure with your own downstream gauge or sensor, or fit a separate instrument near the circuit. The L regulating band itself is unchanged: 0.03-0.4 MPa, within a 1.0 MPa maximum supply.
