AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR20006JN

Genuine AirTAC piston pressure regulator, order code SDR20006JN from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR200 · PT1/8
  • Type and bracketStandard, no bracket (J)
  • Pressure gaugeNo gauge (N)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$15.32 $22.82Save 32%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR20006JN

The SDR20006JN is the bare-panel version of the AirTAC SDR200 piston back-pressure regulator in the 1/8 port size. The ordering code breaks down as 200 for the larger series body, 06 for the 1/8 port, PT thread as standard, J to omit the mounting bracket and N to omit the pressure gauge. As a piston back-pressure type it keeps output pressure stable in circuits that do not need high regulating accuracy but do need a small, cost-effective unit.

The standard type regulates 0.05 to 0.9 MPa with a maximum operating pressure of 1.0 MPa (145 psi), proof pressure of 1.5 MPa (215 psi) and a working temperature of -20 to +70 C. Because both the bracket and the gauge are left out, you bolt the body straight into your own panel or manifold and connect your own indicating gauge where you actually need it.

Airtac SDR Pressure Regulator SDR20006JN Technical Specifications

Order codeSDR20006JN
ProductPiston Pressure Regulator
Model and portSDR200 · PT1/8
Type and bracketStandard, no bracket (J)
Pressure gaugeNo gauge (N)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

Pick SDR20006JN instead of SDR20006 when you already have panel-mounted gauges and want the regulator body only, since blank codes 20006 come with both bracket and gauge. Choose it over SDR20006L1 or SDR20006LJ1 if your setpoint can rise above 0.4 MPa, because those L codes limit the range to 0.03-0.4 MPa. If your line needs a larger 1/4 port, step up to the SDR20008 siblings; if you want the smallest footprint, compare the SDR100 body in the same 1/8 port size.

Applications

tune

Compact machine sub-panels

Ideal for tight electrical-pneumatic cabinets where the machine already has a main gauge, so the SDR20006JN supplies a stable 1/8-port regulated branch without adding a bracket or duplicate gauge.

settings

OEM manifolds

Suited to builders who integrate several regulators on one manifold plate; the bracketless J-code body bolts directly to the plate and the N-code keeps each station lean.

factory

Secondary circuit trimming

Use it downstream of a main filter-regulator to set a stable 0.05-0.9 MPa feed for actuators or air tools that need their own lower pressure than the plant supply.

FAQ

What are the key specifications of the SDR20006JN?

This code is an SDR200 piston back-pressure regulator with a PT1/8 port (06), PT thread, standard regulating range 0.05-0.9 MPa, maximum pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, fluid air, and it is supplied without a mounting bracket (J) and without a pressure gauge (N).

What do the J and N codes change on this order code?

J deletes the mounting bracket and N deletes the pressure gauge, so you receive the regulator body only; the gauge scale codes 1 (MPa), 2 (psi) and 3 (bar) do not apply to the N variant. If you later need onboard indication or foot mounting, reorder as SDR20006, or as SDR20006L1 or SDR20006LJ1 when your setpoint stays below 0.4 MPa.
