AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR20006L1

Genuine AirTAC piston pressure regulator, order code SDR20006L1 from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR200 · PT1/8
  • Type and bracketLow-pressure (L), with bracket
  • Pressure gaugeMPa gauge (1)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$19.30 $26.80Save 27%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR20006L1

The SDR20006L1 is the low-pressure build of the AirTAC SDR200 piston back-pressure regulator. In this code, L selects the low-pressure type with a regulating range of 0.03 to 0.4 MPa instead of the standard 0.05-0.9 MPa, 1 selects the MPa-scale gauge, and the blank J position means the mounting bracket is included. The 06 port code gives a PT1/8 connection on the larger series body.

Like every SDR unit it is a compact, cost-effective piston back-pressure regulator for circuits that do not need high regulating accuracy but do need stable output. Maximum operating pressure is 1.0 MPa (145 psi), proof pressure is 1.5 MPa (215 psi) and the working range is -20 to +70 C, so the low-pressure L setting can still sit safely on a 1.0 MPa supply line.

Airtac SDR Pressure Regulator SDR20006L1 Technical Specifications

Order codeSDR20006L1
ProductPiston Pressure Regulator
Model and portSDR200 · PT1/8
Type and bracketLow-pressure (L), with bracket
Pressure gaugeMPa gauge (1)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

Choose SDR20006L1 when your set pressure stays below 0.4 MPa and you want the ready-to-mount package: bracket included and the MPa-scale gauge already fitted, which saves buying a separate gauge for a 1/8-port branch. If you mount on your own panel and already read pressure elsewhere, SDR20006LJ1 is the same L-range body without the bracket, while SDR20006JN covers the wider standard 0.05-0.9 MPa range. For a 1/4 port in the same low-pressure style, move to the SDR20008 L builds.

Applications

compress

Delicate-part clamping

The 0.03-0.4 MPa L range lets you set gentle, stable clamping force on thin sheet, plastic or finished surfaces without stepping down from a wide-range regulator.

science

Low-pressure test benches

Well suited to bench rigs that feed low-pressure air to sensors, seals or cylinders, with the MPa gauge giving direct readout of the low setpoint during checks.

valve

Pilot-air supply branches

Use it to feed pilot or signal lines from a 1.0 MPa plant supply, where the L-type range gives finer low-end adjustment than the standard SDR20006.

FAQ

What are the key specifications of the SDR20006L1?

This code is an SDR200 piston back-pressure regulator with a PT1/8 port (06), low-pressure L type regulating 0.03-0.4 MPa, MPa-scale gauge (code 1), mounting bracket included, maximum pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, fluid air.

Why order the L version instead of the standard SDR20006?

The L code lowers the regulating range to 0.03-0.4 MPa, which gives finer control near the bottom of the scale when your working setpoint never exceeds 0.4 MPa; the standard type starts at 0.05 MPa and runs to 0.9 MPa. Both share the same 1.0 MPa maximum supply pressure, so you can fit the L version on a normal 1.0 MPa line and still dial in very low outlet settings.
