Genuine AirTAC piston pressure regulator, order code SDR20006LJ1 from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
The SDR20006LJ1 combines the low-pressure L type of the AirTAC SDR200 series with the bracketless J option. You get a piston back-pressure regulator regulating 0.03 to 0.4 MPa through a PT1/8 port (06), with the MPa-scale gauge (code 1) fitted on the body, but no mounting bracket, so the unit integrates straight into a panel, manifold or existing SDR mount.
The L range is the key difference from the standard type: instead of 0.05-0.9 MPa, the low-pressure version is tuned for settings up to 0.4 MPa, while maximum operating pressure stays at 1.0 MPa (145 psi), proof pressure at 1.5 MPa (215 psi) and the temperature range at -20 to +70 C. It keeps the series character of a small, simple and easy-to-install regulator with stable output for circuits that value low cost over high regulating accuracy.
| Order code | SDR20006LJ1 |
|---|---|
| Product | Piston Pressure Regulator |
| Model and port | SDR200 · PT1/8 |
| Type and bracket | Low-pressure (L), no bracket (J) |
| Pressure gauge | MPa gauge (1) |
| Structure | Piston back-pressure type |
|---|---|
| Fluid | Air |
| SDR100 ports | M5 / 1/8 |
| SDR200 ports | 1/8 / 1/4 |
| Regulating range | 0.05-0.9 MPa (standard), 0.03-0.4 MPa (L) |
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.
Order SDR20006LJ1 over SDR20006L1 when you do not need the foot bracket, for example when panel or manifold mounting makes it redundant; everything else, including the MPa gauge and the 0.03-0.4 MPa L range, stays identical. Compared with the standard-range SDR20006JN, this code trades the wider 0.05-0.9 MPa range for finer low-pressure adjustment below 0.4 MPa, and compared with SDR20006JN it keeps onboard MPa indication. For a 1/4 port in the L style, look at the SDR20008 L builds.
Fits builders who mount several low-pressure regulators side by side on one prepared panel, keeping the MPa gauge at each station while the J code removes unused brackets.
Suited to replacing or adding a low-pressure stage on machines that already have a bracket or panel cutout, so the SDR20006LJ1 body slots in without duplicate hardware.
Use the 0.03-0.4 MPa L range to feed gentle air jets, sealing stations or product-handling actuators on packaging lines, reading the setpoint directly off the built-in MPa gauge.
This code is an SDR200 piston back-pressure regulator with a PT1/8 port (06), low-pressure L type regulating 0.03-0.4 MPa, MPa-scale gauge (code 1), no mounting bracket (J), maximum pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, fluid air.
Against SDR20006L1 the only change is the J option: this code omits the mounting bracket while keeping the same L range and MPa gauge. Against SDR20006JN the change is the L option: this code covers 0.03-0.4 MPa instead of the standard 0.05-0.9 MPa and adds the onboard MPa gauge that the JN code leaves out. Confirm port and thread details from the datasheet before ordering in volume.
