AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR20006LJN

Genuine AirTAC piston pressure regulator, order code SDR20006LJN from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR200 · PT1/8
  • Type and bracketLow-pressure (L), no bracket (J)
  • Pressure gaugeNo gauge (N)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$15.32 $22.82Save 32%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR20006LJN

The SDR20006LJN is the low-pressure, gauge-free, bracket-free build of the AirTAC SDR200 piston back-pressure regulator. Its PT1/8 port follows the ordering table, where 06 stands for 1/8, and the L code selects the low-pressure spring, which regulates down to 0.03 MPa instead of the 0.05 MPa floor of the standard type.

Because J and N remove the bracket and the gauge, this code is a bare piston regulator body: simple, small and cost-effective, easy to install, with output pressure stable enough for circuits that do not demand high regulating accuracy. Maximum operating pressure is 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), and the fluid is air.

Airtac SDR Pressure Regulator SDR20006LJN Technical Specifications

Order codeSDR20006LJN
ProductPiston Pressure Regulator
Model and portSDR200 · PT1/8
Type and bracketLow-pressure (L), no bracket (J)
Pressure gaugeNo gauge (N)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

The L code sets the regulating range to 0.03-0.4 MPa; choose the standard-range SDR20006N instead when set points climb up to 0.9 MPa. J deletes the mounting bracket, so if you want the body screwed to a panel, order the otherwise identical SDR20006LN. For a 1/4 port on the same low-pressure type, move to SDR20008L, and if a built-in gauge matters, look at the gauged L versions of the SDR200 with scale code 1, 2 or 3.

Applications

sensors

Low-pressure pilot signals

Feeding pilot ports of directional valves or signal circuits that must sit below 0.4 MPa; the L spring starts regulating as low as 0.03 MPa.

packaging

Gentle packaging actuation

Light clamping, box hold-down or tray ejection on packaging machines, where standard-range pressure would be more force than the product tolerates.

science

Bench and leak-test rigs

Test benches that already carry their own panel gauges: the N code supplies low-pressure air without duplicating instrumentation on the rig.

FAQ

What are the key figures of the SDR20006LJN?

It is an SDR200 piston back-pressure regulator with a PT1/8 port. The L low-pressure type regulates 0.03-0.4 MPa, maximum operating pressure is 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), the fluid is air, and the working temperature is -20 to +70 C. The J and N codes mean it comes with neither bracket nor gauge.

What exactly do J and N change on this order code?

J stands for without bracket, so the body must be held by its port connections or another fixing method; the bracketed counterpart is SDR20006LN. N stands for without gauge, and a fitted gauge exists only on codes without N, with scale 1 for MPa, 2 for psi or 3 for bar.
