AirTAC SDR · Piston Pressure Regulator

Airtac SDR Pressure Regulator SDR20006LN

Genuine AirTAC piston pressure regulator, order code SDR20006LN from the SDR range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Model and portSDR200 · PT1/8
  • Type and bracketLow-pressure (L), with bracket
  • Pressure gaugeNo gauge (N)
  • StructurePiston back-pressure type
  • FluidAir
  • SDR100 portsM5 / 1/8
$15.78 $23.28Save 32%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDR model and port, type and bracket and pressure gauge on one page All SDR codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDR Pressure Regulator SDR20006LN

AirTAC builds the SDR20006LN around a piston back-pressure mechanism: a compact, cost-effective way to hold a stable secondary pressure on air lines. The 06 suffix fixes the port at PT1/8, the L code marks the low-pressure type with a 0.03-0.4 MPa regulating range, and the empty thread position means PT.

Unlike its J sibling, this code ships with the mounting bracket, so the body can be screwed to a plate or frame; unlike the gauged codes it carries no gauge, which keeps the unit minimal. It tolerates 1.0 MPa (145 psi) operating pressure, 1.5 MPa (215 psi) proof pressure and -20 to +70 C on air service.

Airtac SDR Pressure Regulator SDR20006LN Technical Specifications

Order codeSDR20006LN
ProductPiston Pressure Regulator
Model and portSDR200 · PT1/8
Type and bracketLow-pressure (L), with bracket
Pressure gaugeNo gauge (N)
StructurePiston back-pressure type
FluidAir
SDR100 portsM5 / 1/8
SDR200 ports1/8 / 1/4
Regulating range0.05-0.9 MPa (standard), 0.03-0.4 MPa (L)
Max. pressure1.0 MPa (145 psi)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C

Source: AirTAC Products Catalog 2026A (PDF01-P0274), SDR series specifications and ordering code.

How to choose

SDR20006LJN is the identical low-pressure regulator delivered without the bracket, so pick this code when the body needs a fixed mounting point. Compared with SDR20006N, this L version regulates 0.03-0.4 MPa rather than the standard 0.05-0.9 MPa, which suits set points that never rise above 0.4 MPa; if they might, the standard range is the safer pick. For a 1/4 port with the same low-pressure behaviour, the sibling code is SDR20008L.

Applications

build

Panel and frame mounting

The included bracket lets the PT1/8 body be screwed to a manifold plate, machine frame or mounting plate wherever a low-pressure branch is needed.

compress

Low-force clamping fixtures

Holding thin-walled or delicate parts where the clamp pressure must stay inside the 0.03-0.4 MPa window instead of rising toward 0.9 MPa.

settings

Adding a low-pressure branch to existing machines

Retrofitting a gentle-air take-off on legacy equipment, with the bracket providing a solid fixing point and the PT1/8 port matching 1/8 plumbing.

FAQ

What are the key figures of the SDR20006LN?

Series SDR200, piston back-pressure type, PT1/8 port, low-pressure (L) regulating range 0.03-0.4 MPa, max operating pressure 1.0 MPa (145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, fluid air, delivered with bracket and without gauge.

When is the L low-pressure range the right choice here?

Choose L when every set point stays below 0.4 MPa and you want finer adjustment in that band, since the range starts at 0.03 MPa. If pressures up to 0.9 MPa are ever needed, order the standard-range SDR20006N with the same PT1/8 port and bracket.
