Airtac SDR Pressure Regulator SDR20008J2T
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR Series Pressure Regulator SDR20008J2T Technical Details
- Model: SDR20008J2T (JIS/ISO dual flange compatible)
- Type: Precision pressure regulator with relief valve
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 3,500 L/min (ANR)
- Pressure gauge interface: M5×0.8 dual gauge ports
- Adjustment knob rotation: 270° with lockable dial
- Weight: 1.25 kg (including mounting hardware)
- Dimensions: 140mm(W) × 85mm(H) × 75mm(D)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Temperature range: -10℃ to 80℃ (150℃ peak for 30 mins)
- Vibration resistance: ≤10 Hz/1.5mm amplitude
- Protection rating: IP54 (dust/water splashes)
- Optional accessories: Pressure gauge SDE200-08, mounting bracket SDA200
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated relief valve enables automatic pressure release during overpressure conditions (≥1.1×set pressure). Equipped with anti-vibration structure and zero-leakage poppet mechanism, optimized for high-cycle applications.
- Plastic injection molding machine pressure control
- Automated assembly line pneumatic tool stations
- CNC machine air bearing systems
- Semiconductor manufacturing gas pressure regulation
- Food packaging line actuator control
Installation guidelines:
Install downstream of filter/lubricator (FRL) units. For vertical mounting,
orient adjustment knob upward. Perform initial pressure setting at maximum
system flow. Requires monthly diaphragm inspection in high-moisture environments.
| Property | Property Value |
|---|---|
| sku | SDR20008J2T |
| Port Size | PT1/4 |
