Airtac SGC Standard Cylinder SGC125X115
The AirTAC Airtac SGC Standard Cylinder SGC125X115 is a genuine double acting ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 115mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke115 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGC Standard Cylinder SGC125X115
Delivering 6136 N of push force at 0.5 MPa, this double-acting 125 mm bore cylinder handles demanding automation tasks. It features a 115 mm stroke, a G1/2 air port, and a 32 mm carbon steel rod with an M27x2.0 thread. Four steel tie rods clamp the aluminum barrel to the covers, ensuring high rigidity under heavy thrust. The two-way piston seal retains an oil reservoir for continuous lubrication and extended service life.
Because it follows the standardized ISO 15552 mounting interface, this model drops directly into existing large-bore fixtures and shares common accessories. Plan for roughly 3682 N of real work at 0.5 MPa, which equates to lifting about 313 kg vertically with a 2:1 safety margin. The standard TPU seal operates from -20 to +70 C, while a Viton H option extends this to 150 C. Note that this specific SKU lacks the -S magnet, so it cannot accept CMSG, DMSG, or EMSG position switches.
Airtac SGC Standard Cylinder SGC125X115 Technical Specifications
| Model | Airtac SGC Standard Cylinder SGC125X115 |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 115 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGC Standard Cylinder SGC125X115
| SGC | ISO 15552 tie-rod cylinder (double-acting type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×115 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGC Standard Cylinder SGC125X115 Is Used
Press Fit Assembly
Drives bearings into heavy housings on automated machining lines, utilizing the 6136 N push force to seat components accurately.
Pallet Stopping Gate
Acts as a robust pneumatic stop in high-throughput logistics conveyors, holding back loaded pallets with its 125 mm bore.
Plastic Mold Clamping
Secures injection mold halves during low-pressure closing sequences, relying on the rigid tie-rod construction to prevent deflection.
Is the Airtac SGC Standard Cylinder SGC125X115 the Right Cylinder?
This 125 mm bore is the smallest in the SGC family; if your application requires less force, you would need to look outside this series, while stepping up to the 160 mm bore increases the 0.5 MPa push force significantly to 10053 N. The 115 mm stroke provides ample travel for mid-range motions. Since this model has no -S suffix, it cannot support magnetic sensors. If your design requires position feedback, select the -S magnet variant. Furthermore, a standard double-acting cylinder drifts when air is lost or a valve is centered. The adjustable 40 mm air cushion only decelerates the piston near the end of stroke; to hold a load securely, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGC Standard Cylinder SGC125X115 FAQ
This 125 mm bore cylinder features a G1/2 air port and delivers a push force of 6136 N and a pull force of 5734 N at 0.5 MPa. At 0.7 MPa, the push is 8590 N and pull is 8028 N. The theoretical maximum force is 1251 kgf at 1.0 MPa.
No, this specific SKU does not include a magnet. You must choose the -S variant to use CMSG, DMSG, or EMSG magnetic switches. The unit is built with a standardized ISO 15552 mounting interface, allowing it to interchange with existing large-bore fixtures and accessories.
