Airtac SI200 Standard Cylinder SI200X1000TC
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1000TC Standard Cylinder Specifications
- Model: SI200X1000TC
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: Ø200 mm (±0.1mm manufacturing tolerance)
- Stroke: 1000 mm (adjustable stroke buffer)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Cushion type: External adjustable rubber bumper + internal air cushion
- Mounting style: Basic type (MF1) with front/rear threaded mounting holes
- Port size: G1/2 (BSPP thread) with NBR seals
- Piston rod thread: M30x2 external thread (stainless steel)
- Material: Aluminum alloy barrel (6063-T5), chrome-plated rod (45# steel)
- Seal material: High-grade NBR (Nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Protection rating: IP65 (rod extension area IP54)
- Lubrication: Pre-lubricated (Grease ISOVG32 equivalent)
- Theoretical thrust: 22,000N @ 0.7MPa (extend), 18,500N @ 0.7MPa (retract)
- Weight: 19.8 kg (±5% production variance)
- Dimensions: 1200mm (total length) × 240mm (max width) × 240mm (height)
High-torque industrial cylinder optimized for heavy-duty linear motion applications. Features dual cushioning system with ±5° adjustable stroke end dampers and corrosion-resistant chromium plating. Includes built-in magnet (DIN 43650 compatible) for position sensing. Requires 5-40μm filtered compressed air with max 1mg/m³ oil content.
- Automotive production line clamping fixtures
- Steel coil handling manipulators
- Injection molding machine ejectors
- Paper roll positioning systems
- Shipbuilding jig actuators
Installation guidelines:
Maintain 0.1mm/m alignment tolerance during mounting. Allow minimum 150mm
free space at rod end for maintenance. Perform initial 50 low-pressure
(0.3MPa) test cycles before full operation.
| Property | Property Value |
|---|---|
| sku | SI200X1000TC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
