Airtac SI200 Standard Cylinder SI200X1050S
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1050S Standard Cylinder Specifications
- Model: SI200X1050S
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: Ø200 mm (±0.05mm precision honing)
- Stroke: 1050 mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Port size: G1-1/2 (NPT1-1/2 optional)
- Rod thread: M30×2.0 external thread
- Cushioning: Adjustable pneumatic cushion (both ends)
- Ambient temperature: -20℃ to 80℃
- Seal material: Polyurethane (NBR option available)
- Weight: 38.6 kg (without accessories)
- Dimensions: 1465mm(L) × 220mm(W) × 220mm(H)
- Rod diameter: Ø45mm (chromed steel)
- Mounting: Multiple options (MF1 front flange, MP4 foot, MB1 rear flange)
- Position detection: Built-in magnet (D-M9N sensor compatible)
Heavy-duty industrial cylinder engineered for high-force linear motion applications. Features precision-guided piston movement with wear-resistant rod coating and integrated shock absorption. Requires ISO 8573-1:2010 [4:4:3] class compressed air. Includes auto-switch ready design for position feedback systems.
- Metal stamping press ejection systems
- Automotive assembly line clamping units
- Construction material compression molds
- Shipbuilding plate bending machinery
- Waste recycling balers
Installation guidelines:
Support rod end with alignment coupler when stroke exceeds 800mm.
Apply lithium soap-based grease (NLGI #2) to rod before initial operation.
Allow 50mm clearance behind cylinder for maintenance access.
| Property | Property Value |
|---|---|
| sku | SI200X1050S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1050mm |
