Airtac SI200 Standard Cylinder SI200X1100S
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1100S Standard Cylinder Specifications
- Model: SI200X1100S
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 200 mm
- Stroke: 1100 mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (ISO 228 standard)
- Piston rod thread: M36×2 external thread
- Material: Aluminum alloy barrel, chrome-plated steel rod
- Seal type: NBR (Nitrile) seals
- Weight: 25.8 kg (without accessories)
- Dimensions (L×W×H): 1300×230×230 mm (full extension)
- Mounting options: Basic type (NFAC mounting accessory compatible)
- Position detection: Prepared for magnetic sensor installation (SM/SMF series)
- Protection rating: IP65 (rod seal area)
High-torque industrial cylinder engineered for heavy-duty linear motion applications. Features dual piston seals for leak prevention and chromium-plated rod with wiper ring for contamination resistance. Optional auto-switch grooves allow integration with inductive sensors for position feedback.
- Metal stamping press ejection systems
- Automotive assembly line clamping devices
- Paper roll handling in printing machinery
- Plastic injection molding machine core pulls
- Foundry equipment door actuators
Operational guidance:
Lubricate with ISO VG32 hydraulic oil (air line lubricator recommended).
Avoid side load exceeding 150N. For vertical installations, use locknut
(LBM series) to prevent unintended descent during pressure loss.
- Stroke adjustability: ±5mm tolerance via cushion screw adjustment
- Rod end types: Female thread (standard), clevis, or flange options
- Custom stroke versions available below 2000mm
| Property | Property Value |
|---|---|
| sku | SI200X1100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1100mm |
