This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI32X100, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI32 Standard Air Cylinder SI32X100
The AirTAC SI32 Standard Air Cylinder SI32X100 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI32X100, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAI32X100
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI32 Standard Air Cylinder SI32X100
The AirTAC SI32X100 is a discontinued double-acting ISO 15552 profile cylinder with a 32mm bore and 100mm stroke. It delivers 402N push force at 0.5MPa via a G1/8 port. AirTAC replaced this with the SAI32X100, a direct upgrade retaining the exact interface, force, and mounting.
The SAI upgrade features a two Y-shaped one-way piston seal for low start-up pressure and long life. This SKU lacks a magnet, so it cannot take a sensor.
Airtac SI32 Standard Air Cylinder SI32X100 Technical Specifications
| Model | Airtac SI32 Standard Air Cylinder SI32X100 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI32X100 |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI32X100 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAI32X100 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI32 Standard Air Cylinder SI32X100
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI32 Standard Air Cylinder SI32X100 Is Used
Small Part Ejection
Uses the 402N push force at 0.5MPa to reliably push lightweight finished components out of a machining center.
Compact Clamping
Secures small workpieces in tight fixture spaces where the 32mm profile barrel and 100mm stroke fit perfectly.
Gate Diverting
Pivots light-duty pneumatic diverter gates on packaging lines, operating efficiently at 30-800mm/s.
Replacing the Airtac SI32 Standard Air Cylinder SI32X100 with the SAI32X100
To replace the SI32X100, order the SAI32X100 and confirm the ISO 15552 mounting, G1/8 port, and M10x1.25 rod thread. Since this specific SKU has no -S magnet, it cannot accept CS1-B/DS1-B sensors; order a magnet-equipped SAI if position detection is needed. For higher force, the neighboring 40mm bore provides 628N at 0.5MPa. The cushion only decelerates; for load holding on air loss, use an external pilot check valve or the SAIL/BSAI lock variants.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI32X100
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI32 Standard Air Cylinder SI32X100 FAQ
Yes, the SI32X100 is discontinued. The direct replacement is the AirTAC SAI32X100. It is dimensionally interchangeable per ISO 15552, matching the 32mm bore, 100mm stroke, G1/8 port, and mounting accessories.
This double-acting cylinder has a G1/8 port and generates 402N push and 345N pull at 0.5MPa, 563N push at 0.7MPa, 724N push at 0.9MPa, and a maximum theoretical force of 82kgf at 1.0MPa.
