Airtac SI32 Standard Air Cylinder SI32X100H
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X100H Standard Cylinder Technical Specifications
- Model: SI32X100H
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: Ø32 mm (±0.1mm manufacturing tolerance)
- Stroke: 100 mm (adjustable stroke stopper optional)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/ -10℃ to 70℃ (FKM seals)
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (G1/8 adapter available)
- Mounting style: Basic type (MF1) with 32mm center mounting hole spacing
- Rod end thread: M10x1.25 (male)
- Tube material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR standard (FKM available for high temp)
- Weight: 1.25 kg (without accessories)
- Dimensions: 178mm (L) × 50mm (W) × 50mm (H) (retracted state)
- Extended length: 278mm (retracted length + stroke)
- Max theoretical force: 255N @ 0.63MPa
- Air consumption: 0.25L/stroke @ 0.5MPa
High-precision industrial cylinder featuring wear-resistant chromium-molybdenum piston rod and corrosion-resistant aluminum barrel. The SI32 series utilizes a dual-seal design (rod seal + piston seal) for leak prevention. Requires 40μm filtered lubricated air (ISO 8573-1 class 4). Includes magnetic piston (D-M9 proximity sensor compatible) for position feedback.
- Carton sealing machine pusher mechanisms
- CNC machine tool clamping devices
- Automated conveyor gate controls
- Plastic injection molding ejectors
- Textile machinery tensioning systems
Installation guidelines:
Maximum side load ≤15% of thrust capacity. For vertical mounting,
use rod-down orientation. Lubricate with ISO VG32 turbine oil
if using non-lubricated air supply. Allow 10mm clearance
for magnetic sensors.
| Property | Property Value |
|---|---|
| sku | SI32X100H |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
