Airtac SI32 Standard Air Cylinder SI32X100SH
$59.98
Regular price
$67.48
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SI32X100SH
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) compliant compact pneumatic cylinder
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, install locking nut (AN5) to prevent piston rod rotation.
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X100SH Standard Cylinder Specifications
- Model: SI32X100SH
- Bore size: 32mm
- Stroke: 100mm
- Operation type: Double-acting
- Working pressure: 0.05-1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Piston speed: 50-1000mm/s
- Mounting style: Standard (MF1 basic type)
- Rod end thread: M14×1.5
- Port size: G1/8 (NPT1/8 optional)
- Seal material: Polyurethane (NBR optional)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Weight: 1.45kg (with rod and mounting accessories)
- Dimensions:
- Extended length: 218mm
- Retracted length: 118mm
- Body diameter: 42mm
- Mounting hole spacing: 25mm (center-to-center)
High-precision industrial cylinder with ISO 6432 compliance, featuring wear-resistant chromium plating and dual cushioning adjustment. The anodized aluminum construction ensures corrosion resistance in humid environments. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- Automated assembly line clamping mechanisms
- CNC machine tool part ejection systems
- Printing press paper feed controls
- Packaging machine sealing head actuation
- Automotive welding fixture positioning
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, install locking nut (AN5) to prevent piston rod rotation.
| Property | Property Value |
|---|---|
| sku | SI32X100SH |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
