Airtac SI32 Standard Air Cylinder SI32X100SN
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X100SN Standard Cylinder Technical Specifications
- Model: SI32X100SN
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 32mm (±0.1mm precision honing)
- Stroke: 100mm (adjustable cushioning)
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod thread: M12×1.25 (external)
- Mounting style: SN-type (basic front flange)
- Seal material: Nitrile Butadiene Rubber (NBR)
- Protection rating: IP65 (standard wiper design)
- Weight: 1.28kg (without accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (at full extension)
- Rod end type: Female thread with cushion screw
- Theoretical thrust: 255N @0.5MPa (push side)
- Max speed: 500mm/s (with cushion adjustment)
High-precision industrial cylinder featuring hard-anodized aluminum tube (surface hardness HV400+) and chrome-plated piston rod (20μm coating thickness). Integrated magnet groove (T-slot) for sensor mounting enables position feedback. Optional auto switch models available (SI32X100SN-M9BW). Requires 40μm filtered air with ISO VG32 lubricant recommendation.
- Packaging line clamping mechanisms
- CNC machine tool jig positioning
- Automated conveyor gate control
- Plastic injection molding ejectors
- Semiconductor wafer handling systems
Installation guidance:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Use lock nuts (M12) with 12-15N·m torque specification. Lubricate through
air port monthly in dry environments.
| Property | Property Value |
|---|---|
| sku | SI32X100SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
