This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI32X100TC, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI32 Standard Air Cylinder SI32X100TC
The AirTAC SI32 Standard Air Cylinder SI32X100TC is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI32X100TC, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAI32X100TC
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI32 Standard Air Cylinder SI32X100TC
The AirTAC SI32X100TC is a discontinued double-acting ISO 15552 profile cylinder with a 32mm bore and 100mm stroke. It delivers 402N push force at 0.5MPa via a G1/8 port. The direct replacement is the SAI32X100TC, matching the bore, stroke, force, port, and TC trunnion mount.
The SAI upgrade features two Y-shaped one-way piston seals for low start-up pressure and long life. This no-magnet SKU cannot take a sensor, unlike the CS1-B/DS1-B compatible -S versions.
Airtac SI32 Standard Air Cylinder SI32X100TC Technical Specifications
| Model | Airtac SI32 Standard Air Cylinder SI32X100TC |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI32X100TC |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI32X100TC carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAI32X100TC produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI32 Standard Air Cylinder SI32X100TC
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI32 Standard Air Cylinder SI32X100TC Is Used
Small Part Ejection
Uses the 402N push force at 0.5MPa to push lightweight machined components out of a fixture on an automated line.
Package Diverting
Actuates a routing gate on a conveyor system, where the 100mm stroke provides just enough travel to redirect small boxes.
Clamp Actuation
Secures thin workpieces in a welding jig, taking advantage of the compact 32mm ISO 15552 profile barrel to fit tight cells.
Replacing the Airtac SI32 Standard Air Cylinder SI32X100TC with the SAI32X100TC
To replace the SI32X100TC, order the SAI32X100TC. Verify the ISO 15552 TC trunnion interface, 32mm bore, 100mm stroke, G1/8 port (PT/G/NPT thread options), and note this non-magnet SKU cannot accept a CS1-B/DS1-B sensor. Sizing both ways: the neighbouring 40mm bore yields 628N push at 0.5MPa, while dropping to 25mm stroke reduces rod extension. A plain cylinder drifts on air loss—the cushion only decelerates—so for load holding use an external pilot check valve or the SAIL/BSAI lock variants. The SAIF variant adds a built-in valve if needed.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI32X100TC
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI32 Standard Air Cylinder SI32X100TC FAQ
Yes, the SI32X100TC is discontinued. The direct replacement is the SAI32X100TC. It is dimensionally interchangeable per ISO 15552, matching the 32mm bore, 100mm stroke, 402N force, G1/8 port, and TC trunnion mount.
This double-acting cylinder has a G1/8 port, M10x1.25 rod thread, and 27mm cushions. It provides 402N push and 345N pull at 0.5MPa, 563N push at 0.7MPa, 724N push at 0.9MPa, and a maximum theoretical force of 82kgf at 1.0MPa. Speed is 30-800mm/s.
