This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ125X1000-30, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30
The AirTAC SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø125mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ125X1000-30, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ125 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM27×2.0
- StatusDiscontinued → SAIJ125X1000-30
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30
The AirTAC SIJ125X1000-30 is a discontinued double-acting double-rod ISO 15552 adjustable-stroke cylinder with a 125mm bore and 1000mm maximum stroke. An external stop screw lets you trim the extend stroke by up to 30mm on-site, yielding a usable 970-1000mm stroke. The direct replacement is the SAIJ125X1000-30, matching the interface, force, and mounting.
The SAIJ upgrade features a two Y-shaped one-way piston seal for lower start-up pressure and longer life. Note this SKU lacks a -S magnet, so it cannot take a switch. The stop screw sets end position only; it is not a load lock, so use an external rod lock for held loads.
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 Technical Specifications
| Model | Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ125X1000-30 |
| Bore size | Ø125 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ125X1000-30 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
The SAIJ125X1000-30 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 125 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 Is Used
Press Stroke Calibration
Trimming the extend stroke by up to 30mm on-site allows exact positioning of large pressing tools without machining custom spacers.
Heavy Divertor Adjustment
A 125mm bore moving heavy pallets can fine-tune the diverting arm end position by 30mm to accommodate varying product widths.
Pallet Stop Tuning
Field-tuning the 1000mm extend stroke lets operators set the exact stopping point for mixed pallet sizes on a handling line.
Replacing the Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 with the SAIJ125X1000-30
To replace the discontinued SIJ125X1000-30, order the direct replacement SAIJ125X1000-30, which preserves the 30mm adjust window, 1000mm max stroke, G1/2 port, and ISO 15552 mounting. Choose the 30mm adjust window if you need precise 970-1000mm extend tuning. Reuse FA, LB, or TC mounts. Because this SKU has no -S magnet, it cannot accept a sensor; add external detection if needed. For the 1000mm stroke, use external guides to prevent rod bending and manage side loads.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ125X1000-30
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-30 FAQ
Yes, the SIJ125X1000-30 is discontinued. The direct replacement is the SAIJ125X1000-30. It shares the same ISO 15552 interface, 125mm bore, 1000mm max stroke, 30mm adjust window, G1/2 port, and mounting options, while upgrading the piston seal.
The 30mm external stop screw window allows a usable extend stroke of 970-1000mm. The stop screw sets end position only and is not a load lock.
