This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ32X100-40, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40
The AirTAC SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ32X100-40, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAIJ32X100-40
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40
The AirTAC SIJ32X100-40 is a discontinued double-acting double-rod ISO 15552 adjustable-stroke cylinder. An external stop screw lets you trim the extend stroke by up to 40mm on-site, yielding a usable 60-100mm stroke from the 100mm nominal maximum.
As this SIJ is end-of-life, the direct replacement is the SAIJ32X100-40, matching the ISO 15552 interface, force, and mounting. The SAIJ upgrade uses a two Y-shaped one-way piston seal for low start-up pressure and long life. The stop sets end position but is not a load lock; use SAIL/BSAI or an external rod lock for held loads.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 Technical Specifications
| Model | Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ32X100-40 |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ32X100-40 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAIJ32X100-40 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 Is Used
Actuator Reach Calibration
Trimming the extend stroke by up to 40mm on-site to dial in the exact contact point for a light-duty 32mm bore pressing or forming task.
Variable Length Diverter
Adjusting the extend stop externally to tune the pusher length without disassembling the cylinder mount when product sizes change.
Compact End-Stop Tuning
Setting a precise 60-100mm extend position for a lightweight routing gate where the full 100mm stroke would overshoot the target.
Replacing the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 with the SAIJ32X100-40
To replace the discontinued SIJ32X100-40, order the direct replacement SAIJ32X100-40. Size both ways using 0.5MPa push force: the 32mm bore yields 402N, while the neighbouring 40mm bore yields 628N. Choose the 40mm adjust window if your field stroke tuning requires trimming the extend by up to 40mm. Mounting interfaces (Basic, FA, LB, TC) are reused. This SKU lacks the -S magnet and cannot take a magnetic switch. For strokes >=300mm, verify side-load tolerance. The stop screw sets end position and does not hold loads on air loss.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ32X100-40
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-40 FAQ
Yes, the SIJ32X100-40 is discontinued. The direct replacement is the SAIJ32X100-40. It matches the ISO 15552 interface, 32mm bore, 100mm nominal stroke, 40mm adjust window, G1/8 port, and mounting. The SAIJ family also adds an upgraded two Y-shaped one-way piston seal for lower start-up pressure.
The external stop screw window is 40mm, allowing an on-site extend stroke trim from the 100mm maximum down to 60mm. The stop sets end position but is not a load lock; use an external rod lock or SAIL/BSAI for held loads.
