Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-50
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X100-50 Double Rod Adjustable Cylinder Specifications
- Model: SIJ32X100-50
- Type: Double rod adjustable stroke cylinder (ISO 6432 compliant)
- Bore size: Ø32 mm (±0.1mm tolerance)
- Stroke: 100 mm (adjustable via built-in stroke screws)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Standard FS-type (basic) with multiple mounting options via 4x M5 threaded holes
- Port size: G1/8 (NPT1/8 optional)
- Piston rod diameter: Ø12mm (chrome-plated steel)
- Max speed: 500 mm/s (with cushion)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel (hard anodized), POM end caps
- Weight: 1.85 kg (excluding accessories)
- Dimensions:
- Length: 196mm (min. retracted) / 296mm (max. extended)
- Width: 76mm (including rod brackets)
- Height: 76mm (square profile)
Precision double rod cylinder featuring micrometer-style stroke adjustment (±1mm accuracy) through rotary end caps. The symmetrical dual-rod design eliminates lateral deflection during operation, making it ideal for applications requiring precise linear motion and high moment resistance. Includes wear-resistant DU bushing and IP54-rated wiper seals.
- Precision clamping fixtures in CNC machining centers
- Vertical Z-axis positioning in PCB drilling machines
- Material handling systems requiring dual-sided force application
- Automated optical inspection (AOI) equipment alignment
- Packaging machine stopper mechanisms
Installation tip:
Maintain 0.05-0.1mm clearance between rod ends and load connection points to prevent side load stress. Lubricate with ISO VG32 turbine oil before initial use. For vertical installations, use the upper port as exhaust to prevent piston drift.
| Property | Property Value |
|---|---|
| sku | SIJ32X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
