Airtac STWB Slide Table Cylinder STWB10X75S
Genuine AirTAC slide cylinder, order code STWB10X75S from the STW range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- MountingBody fixed (STWB)
- BoreØ10 mm
- Stroke75 mm
- ActionDouble acting, twin rod
- CushionHydraulic shock absorber
- Ø1050.3 N at 0.5 MPa · port M5×0.8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac STWB Slide Table Cylinder STWB10X75S
In the AirTAC STW ordering code, the B position means the mounting is taken through the cylinder body, while the sibling STWA10X75S would be fixed by its end plate. This Dia 10 twin-rod slide delivers 50.3 N theoretical force at 0.5 MPa over a 75 mm stroke, the mid step of the Dia 10 range that runs 25 to 100 mm in 25 mm increments.
Hydraulic shock absorbers slow both stroke ends to cut impact and extend cylinder life, and anti-rotation is held to +/-0.1 deg on this bore. Twin piston rods carry larger moving and side loads, and three sets of M5x0.8 ports let you pick the piping direction. The built-in magnet sits behind the sensor mounting rail, and the unit runs on air filtered to 40 um at 30 to 500 mm/s and -20 to +70 C.
Airtac STWB Slide Table Cylinder STWB10X75S Technical Specifications
| Order code | STWB10X75S |
|---|---|
| Product | Slide Cylinder |
| Mounting | Body fixed (STWB) |
| Bore | Ø10 mm |
| Stroke | 75 mm |
| Action | Double acting, twin rod |
|---|---|
| Cushion | Hydraulic shock absorber |
| Ø10 | 50.3 N at 0.5 MPa · port M5×0.8 |
| Ø16 | 122.5 N at 0.5 MPa · port M5×0.8 |
| Ø20 | 201.1 N at 0.5 MPa · port M5×0.8 |
| Ø25 | 289.8 N at 0.5 MPa · port PT1/8 |
| Ø32 | 490.1 N at 0.5 MPa · port PT1/8 |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.2-1.0 MPa (Ø10), 0.15-1.0 MPa (Ø16-32) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Speed | 30-500 mm/s |
| Stroke tolerance | +1.0 / 0 mm (≤100), +1.5 / 0 mm (>100) |
| Anti-rotation | ±0.1° (Ø10), ±0.05° (Ø16, 20), ±0.03° (Ø25, 32) |
| Port | M5×0.8 (Ø10-20), PT1/8 (Ø25, 32) |
Source: AirTAC Products Catalog 2026A (PDF01-P0547..P0548), STW series specifications, theoretical force, strokes and ordering code.
How to choose
Choose STWB10X75S when your machine fixes the unit through its body; if the bracket bolts to an end plate, order STWA10X75S instead. Within the Dia 10 bore the neighbouring strokes are STWB10X50S and STWB10X100S, so 75 mm suits travels between those two. Note that Dia 10 needs the higher minimum pressure of 0.2 MPa versus 0.15 MPa for larger bores, and if 50.3 N at 0.5 MPa is not enough force, step up to a Dia 16 code such as STWB16X100S rated at 122.5 N.
Applications
Light pick-and-place
The 75 mm travel and +/-0.1 deg anti-rotation suit a small slide carrying a light gripper or vacuum cup between two fixed positions, with the magnet confirming end positions through the sensor rail.
Reject gate on a small line
Mounted body-fixed to a bracket beside the conveyor, the 50.3 N force at 0.5 MPa is enough to push small parts off the flow, while the hydraulic absorbers damp the push at each end.
Sensor-guided positioning
Because this code includes the built-in magnet behind the sensor mounting rail, reed or hall switches can be clipped on directly, so no separate magnet option is needed for position feedback.
FAQ
What are the key figures for the STWB10X75S?
Dia 10 mm twin-rod slide cylinder, 75 mm stroke, body-fixed (B) mounting, 50.3 N theoretical force at 0.5 MPa, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), M5x0.8 ports in three sets, anti-rotation +/-0.1 deg, speed 30-500 mm/s, temperature -20 to +70 C, air filtered by a 40 um element, built-in magnet with sensor mounting rail.
How does the B mounting differ from the A version of the same cylinder?
In the STW ordering code, STWB is fixed through the cylinder body and STWA through its end plate, so STWB10X75S should be chosen when the surrounding machine bolts to the body. Both mountings keep the same Dia 10 performance, the 75 mm stroke and the magnet with its sensor rail.
