Airtac X-AHVFF Manual Valve X-AHVFF0606B
AirTAC X-AHVFF0606B Manual Valve Technical Details
- Full model code: X-AHVFF0606B (base model with locking lever)
- Valve type: 3-position (center closed), 4-way manual directional control
- Port configuration: 6 ports (P, A, B, T1, T2, R)
- Port size: PT1/4 (BSPP) with 6mm pneumatic tubing compatibility
- Operating pressure range: 0.05–1.0 MPa (7–145 PSI)
- Maximum flow rate: 700 NL/min (ANR) at 0.5 MPa
- Actuation force: ≤25N lever operation
- Body material: Anodized aluminum alloy (hard coating for scratch resistance)
- Seal material: HNBR rubber (-20℃ to 80℃) / Optional FKM (-10℃ to 150℃)
- Weight: 220g ±5% (excluding accessories)
- Dimensions: 52mm(L) × 32mm(W) × 85mm(H) (actuator lever adds 15mm height when engaged)
- Mounting pattern: ISO 15407-1 compliant with 25mm modular spacing
- Leakage rate: ≤5 bubbles/min (internal leakage at max pressure)
- Vibration resistance: 10–55Hz with 1.5mm amplitude
Industrial-grade manual override valve featuring positive center position lock and modular design. The X-AHVFF0606B's dual exhaust paths (T1/T2) enable rapid cylinder decompression, while its ergonomic lever provides tactile feedback during mode switching. Specialized coating prevents galvanic corrosion in humid environments.
- Emergency override in automated production lines
- Jig and fixture control in CNC machining centers
- Maintenance bypass for robotic actuator systems
- Educational pneumatic training equipment
- Mobile hydraulic/pneumatic hybrid systems
Installation protocol:
Apply thread sealant only on male ports (PT1/4). For vertical mounting,
orient lever movement parallel to operator's line of sight. Perform
monthly lubrication of pivot points using silicone-based grease.
