Airtac X-AHVSF Handle Valve X-AHVSF0601B
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
AirTAC X-AHVSF0601B Manual Valve Technical Details
- Model: X-AHVSF0601B
- Type: 3-position manual selector valve (detented operation)
- Port configuration: 1/4" BSPP (G1/4) female threads
- Flow capacity: 750 L/min (Cv=1.3 at 0.5MPa)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 70℃
- Body material: Aluminum alloy with hard anodized finish
- Seal material: HNBR (Hydrogenated Nitrile) for oil resistance
- Handle torque: ≤3 N·m
- Weight: 480±10g (including fittings)
- Dimensions: 98mm(L) × 45mm(W) × 82mm(H)
- Port spacing: 18mm between centers
- Leakage rate: <0.1 mL/min under max pressure
- Mounting options: Panel mount with M5 fasteners or direct piping
Industrial-grade manual flow control valve featuring positive center position locking and tactile feedback. The chrome-plated brass spindle ensures smooth operation over 500,000 cycles. Integrated O-ring groove design prevents seal extrusion under pulsating pressures. Compatible with ISO 8573-1:2010 [3:4:3] class compressed air.
- Emergency shutdown systems in pneumatic circuits
- Manual override for automated production lines
- Air flow distribution in plastic injection molding machines
- Pressure regulation in semiconductor wafer handling equipment
- Mobile hydraulic/pneumatic hybrid systems
Installation guidelines:
Apply 2-3 drops of ISO VG32 hydraulic oil to the stem monthly.
Avoid side-loading during handle operation. For vertical installations,
ensure exhaust ports face downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | X-AHVSF0601B |
