Airtac X-AHVSS Manual Valve X-AHVSS0101B
AirTAC X-AHVSS0101B Manual Valve Technical Specifications
- Model: X-AHVSS0101B
- Type: 3/2-way manual push-pull valve (spring return)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 600 NL/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃
- Actuation force: ≤25N
- Weight: 320g ±5% (including fittings)
- Dimensions: 72mm(L) × 40mm(W) × 50mm(H) (excluding handle protrusion)
- Mounting style: Direct pipe mounting with dual M5 mounting holes
- Pressure resistance: 1.5 MPa (proof pressure)
- Cycle life: ≥500,000 operations
Ergonomic manual control valve with positive tactile feedback, featuring double-seal structure for leak-free performance. The optimized flow path design minimizes pressure drop, while the knurled actuator surface ensures slip-resistant operation even with oily hands. Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency stop circuits in production line equipment
- Manual override in automated assembly systems
- Pneumatic training equipment controls
- Material handling system bypass operations
- Test bench pressure regulation
- Food processing machinery (HNBR seals compatible with food-grade lubricants)
Installation note:
Install with arrow direction matching airflow. For horizontal mounting,
use support bracket (optional accessory). Lubricate threads with PTFE tape
during installation. Allow 15mm clearance behind actuator for full stroke operation.
