Airtac X-AHVSS Manual Valve X-AHVSS0403B
AirTAC X-AHVSS0403B Manual Valve Technical Details
- Model: X-AHVSS0403B
- Type: 3-position manual selector valve (lockable)
- Port configuration: 4 ports / 3 positions
- Port size: PT1/4 (BSPP 1/4")
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Maximum flow rate: 500 L/min (ANR)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃
- Body material: Aluminum alloy (anodized finish)
- Handle type: T-bar lever with position indicator
- Weight: 250g ±5%
- Dimensions: 85mm(L) × 30mm(W) × 35mm(H)
- Mounting style: Panel mount (with M5 threaded holes)
- Protection rating: IP54 (dust protected, water splashed)
Robust manual override valve featuring positive center position locking mechanism. Designed for pneumatic system maintenance, emergency operation, and manual mode switching. The ergonomic T-handle provides tactile feedback with 90° rotation between positions. Includes dual O-ring seals for leak-free performance.
- Production line emergency stop systems
- Pneumatic cylinder manual override control
- Air compressor maintenance bypass
- Training simulator pneumatic circuits
- Hydraulic system pilot pressure control
Installation guidance:
Mount in accessible locations with full handle rotation clearance.
Apply thread sealant (PTFE tape recommended) on port connections.
Lubricate O-rings with silicone grease annually.
| Property | Property Value |
|---|---|
| sku | X-AHVSS0403B |
