Airtac X-APC Threaded Straight Connector X-APC6M8X1
AirTAC X-APC6M8X1 Threaded Straight Fitting Specifications
- Model: X-APC6M8X1
- Type: Metric threaded straight connector (male-to-male)
- Thread specification: M8×1.0 (dual-end external thread)
- Material: Nickel-plated brass (base) + NBR seals
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Surface treatment: Electroless nickel plating (≥8μm thickness)
- Weight: 14.5±0.5g
- Dimensions: 25mm(L) × 8mm(D) × 8mm(W)
- Torque rating: 3.5-4.5 N·m installation torque
- Fluid compatibility: Air, inert gases, vacuum
A precision-machined pneumatic fitting designed for compact pneumatic circuits requiring metric thread connections. Features triple-sealing structure with primary metal-to-metal seal and secondary O-ring backup. Anti-vibration grooves prevent loosening in high-frequency applications. Rated for 500,000+ mating cycles.
- Modular pneumatic manifold interconnections
- Sensor mounting brackets in robotic arms
- Vacuum pick-and-place tooling
- Medical device pneumatic controls
- CNC machine tool air blast systems
Installation note:
Apply thread sealant to male threads (PTFE tape recommended). Avoid overtightening -
use torque wrench for consistent sealing. Perform pressure test at 1.25× working
pressure after installation. Compatible with ISO 1179-2 standard ports.
| Property | Property Value |
|---|---|
| sku | X-APC6M8X1 |
