Airtac X-APG Adapter - Reducing Straight Fitting X-APG106
AirTAC X-APG106 Reducer Straight Fitting Technical Details
- Model: X-APG106
- Type: Metric thread reducer union (male-to-female)
- Thread specifications: M5×0.8 (male) to M10×1.0 (female)
- Material: Nickel-plated brass (C3604)
- Seal type: Integrated NBR O-ring
- Pressure range: 0.05–1.5 MPa
- Temperature range: -20℃ to 150℃ (with silicone seals optional)
- Torque limit: 2.5 N·m max
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 8.2g ±0.3g
- Dimensions: 18mm(Length) × 10mm(Major Ø) × 6mm(Minor Ø)
- Fluid compatibility: Air, inert gases, water (non-corrosive media)
- Vibration resistance: ≤15Hz frequency, 1.5mm amplitude
Precision-machined transition fitting for pneumatic line downsizing, featuring dual-thread configuration with corrosion-resistant plating. The tapered seat design ensures bubble-tight sealing up to 1.5MPa without thread sealant. Compatible with push-to-connect tubing systems (4mm OD to 6mm OD transition).
- Branch line pressure reduction in automation workcells
- Sensor air supply line adapters
- Medical device pneumatic manifolds
- Robotic end-effector plumbing transitions
- Compressed air distribution in tight spaces
Installation protocol:
Hand-tighten until seated, then apply 1/4 turn with wrench.
Avoid overtightening - use PTFE tape only on male threads if required.
Maximum 30° offset allowance between connected components.
| Property | Property Value |
|---|---|
| sku | X-APG106 |
