Airtac X-APG Adapter - Reducing Straight Fitting X-APG86
AirTAC X-APG86 Reducer Straight Fitting Technical Details
- Model: X-APG86
- Type: Two-stage reducer (male-to-female)
- Material: Brass body with nickel plating
- Thread standards: G1/8 (male) to G1/4 (female)
- Pressure rating: 0.05-1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -20℃ to 80℃
- Weight: 32g ±1g
- Dimensions: 23mm(L) × 16mm(W) × 16mm(H)
- Surface roughness: Ra ≤3.2μm
- Seal compatibility: Works with PTFE tape or liquid thread sealant
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined flow control adapter enabling secure transitions between different pneumatic line sizes. Features corrosion-resistant nickel plating and internal flow channel optimization (15° tapered transition) to minimize pressure drop. Compatible with most inert gases and compressed air systems.
- Pressure regulator outlet connections
- Compact pneumatic manifolds requiring space-saving adapters
- Sensor mounting interfaces in HVAC systems
- Industrial robot tool changers
- Air brake system modifications in commercial vehicles
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Hand-tighten plus 1/4 turn with wrench. Avoid overtightening -
maximum torque 12N·m. Pressure test after assembly.
| Property | Property Value |
|---|---|
| sku | X-APG86 |
