Airtac X-APH Hex Head Elbow Adapter X-APH1204
AirTAC X-APH1204 Hex Elbow Joint Technical Details
- Model: X-APH1204
- Type: External hexagon elbow joint (rotary type)
- Material: Aluminum alloy (surface anodized)
- Thread Specification: M12×1.5 (male thread)
- Applicable Tube OD: Φ12mm (metric series)
- Rotation Angle: 360° continuous rotation
- Max. Torque: 15 N·m
- Pressure Rating: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Hex Size: 17mm AF (across flats)
- Weight: 198±5g
- Dimensions:
- Total Length: 52mm
- Body Diameter: Φ24mm
- Thread Engagement Length: 15mm
- Elbow Bend Radius: 25mm
- Seal Material: HNBR (Hydrogenated Nitrile)
- Vibration Resistance: ≤20m/s²
- IP Rating: IP54 (dust/water protected)
Precision-engineered rotary elbow joint featuring dual-seal technology for leak-free pneumatic connections. The forged aluminum construction provides exceptional durability while maintaining lightweight characteristics. Optimized flow path design reduces pressure drop by 18% compared to standard elbows.
- Robotic arm pneumatic tool changers
- CNC machine tool air curtain systems
- Semiconductor wafer handling equipment
- High-cycle packaging machine actuators
- Food processing pneumatic circuits (NSF compliant)
Installation guidelines:
Apply 243 thread sealant on male threads (DO NOT use PTFE tape).
Tighten to 10-12 N·m torque using 17mm crowfoot wrench.
Perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APH1204 |
