Airtac X-APH Hex Head Elbow Adapter X-APH12M16
AirTAC X-APH12M16 Hexagonal Elbow Joint Technical Details
- Model: X-APH12M16 (ISO 15407-1 compliant)
- Thread specification: M16×1.5 male thread (external hexagon)
- Material: Nickel-plated brass body with NBR seals
- Tube compatibility: Ø12mm OD pneumatic tubing
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -20℃ to +80℃
- Swivel angle: 360° continuous rotation
- Tightening torque: 25-30 N·m (with copper washer)
- Surface treatment: Electroless nickel plating (8-12μm)
- Weight: 148g ±2g
- Dimensions: 24mm (W) × 24mm (D) × 34mm (H)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP54 (standard sealing configuration)
Precision-engineered swivel joint featuring double-sealed ball bearing mechanism for leak-free operation under dynamic conditions. The hexagonal base allows wrench tightening while maintaining 360° rotational flexibility. Nickel plating provides corrosion resistance in humid environments.
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Automated packaging line air knife systems
- Food processing equipment with frequent hose repositioning
- Plastic injection molding machine air circuits
Installation protocol:
Apply 2-3 drops of pneumatic sealant (Parker Super O-Lube recommended)
on threads before assembly. Use 27mm combination wrench for secure
tightening without damaging the hex surfaces. Perform pressure test
at 0.5MPa before full operation.
Compatibility note:
Not suitable for steam applications. When used with PTFE tubing,
install support sleeve (AS-1216S) to prevent tube ovalization under
high vibration.
| Property | Property Value |
|---|---|
| sku | X-APH12M16 |
