Airtac X-APH Hex Head Elbow Adapter X-APH4M10
AirTAC X-APH4M10 Hexagonal Elbow Joint Specifications
- Model: X-APH4M10
- Type: Swivel elbow joint with male thread
- Port size: M10×1.0 (metric fine thread)
- Material: Aluminum alloy (A6063-T5 body) + SUS304 stainless steel swivel
- Surface treatment: Anodized (body), polished (swivel component)
- Max working pressure: 1.0 MPa (10 bar)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Torque resistance: ≤25 N·m tightening torque
- Rotation angle: 360° continuous rotation
- Weight: 38±2g
- Dimensions: 52mm(L) × 24mm(W) × 24mm(H) (body without swivel)
- Swivel range: ±15° angular deflection
- Seal material: NBR (standard), optional FKM for oil resistance
- Leakage rate: ≤3 bubbles/min under 0.5 MPa air pressure
Precision-engineered rotary joint featuring a hardened stainless steel swivel mechanism with triple-lip seal structure. The hexagonal base allows wrench tightening while the elbow design enables flexible tubing routing in confined spaces. Includes anti-vibration washers for shock absorption in high-cycle applications.
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Packaging machinery rotary unions
- Semiconductor equipment gas delivery systems
- Automated assembly line gripper actuators
Installation guidelines:
Apply 2-3 drops of pneumatic oil to swivel joint before initial use.
Use a 8mm hex wrench for installation with 18-22 N·m torque.
Avoid overtightening which may deform aluminum threads.
For vertical mounting, position swivel downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | X-APH4M10 |
