Airtac X-APH Hex Head Elbow Adapter X-APH4M5
$3.58
Regular price
$11.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH4M5
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH4M5 Hexagonal Elbow Joint Technical Specifications
- Model: X-APH4M5
- Type: Swivel elbow joint with external hexagon
- Thread specification: M5×0.8 (male thread)
- Material: C3604 brass body + NBR seals
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃
- Torque resistance: ≤3 N·m
- Surface treatment: Electroplated nickel (3-5μm)
- Weight: 8.2±0.5g
- Dimensions: 18mm(L) × 12mm(W) × 15mm(H)
- Port angles: 360° free rotation ±2° end play
- Leakage rate: ≤5×10⁻⁸ Pa·m³/s (helium tested)
Precision-machined pivot joint featuring anti-vibration locking design with 2-stage O-ring sealing. The hexagonal base allows tool-assisted tightening in confined spaces. Compatible with PTFE tape or liquid thread sealants (max viscosity 500 mPa·s).
Typical Applications:
- Pneumatic sensor mounting brackets
- Robotic end-effector air line connections
- Medical device gas sampling systems
- Semiconductor fab equipment plumbing
- Multi-axis actuator manifolds
Installation protocol:
Apply 1.2-1.8 N·m torque during assembly. Avoid overtightening beyond 90° rotation after seal contact.
For vertical downward ports, use thread-locking compound on male threads.
| Property | Property Value |
|---|---|
| sku | X-APH4M5 |
