Airtac X-APH Hex Head Elbow Adapter X-APH603
AirTAC X-APH603 Hexagonal Elbow Swivel Joint Technical Details
- Model: X-APH603
- Type: Swivel-type male elbow with hexagonal base
- Material: Nickel-plated brass (stainless steel optional)
- Thread specification: R1/8 (BSPT female thread)
- Hose connection: Ø6mm push-in fitting
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃
- Swivel angle: 360° continuous rotation
- Leakage rate: <0.1 NL/min under max pressure
- Weight: 38g ±2g
- Dimensions: 32mm(H) × 19mm(W) × 19mm(D)
- Surface hardness: HV200-250
- Vibration resistance: 10-2000Hz, 10G acceleration
Precision-machined swivel joint featuring dual O-ring seals (NBR material) for leak-free pneumatic connections. The hexagonal base allows tool tightening with 10mm wrench, while the rotating collar enables 360° hose orientation adjustment without torque transfer. Anodized aluminum collar provides wear resistance during repeated adjustments.
- Pneumatic tool air supply line connections
- Robotic arm end effector plumbing
- CNC machine cooling air distribution
- Packaging machine rotary union assemblies
- Medical device gas delivery systems
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads. Tighten with 1.2-1.5N·m torque.
For vertical installations, position the elbow's rotation plane perpendicular
to vibration direction. Replace O-rings every 50,000 cycles in high-usage scenarios.
| Property | Property Value |
|---|---|
| sku | X-APH603 |
