Airtac X-APH Hex Head Elbow Adapter X-APH604
AirTAC X-APH604 Hexagonal Elbow Swivel Joint Technical Details
- Model: X-APH604
- Type: Reusable 90° rotary elbow fitting
- Thread specification: M5×0.8 (external thread) x R1/8 (internal thread)
- Material: Nickel-plated brass body, POM (polyoxymethylene) sealing ring
- Operating pressure: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Rotation angle: ±30° adjustable
- Torque resistance: ≤2.5 N·m tightening torque
- Weight: 18.5±0.3g
- Dimensions: 23.5mm (L) × 14.8mm (W) × 21.6mm (H)
- Surface hardness: HV300-400 (nickel plating)
- Leakage rate: ≤20 cm³/min at 0.5 MPa
Precision-engineered swivel joint featuring dual-axis rotation capability for flexible tubing alignment in confined spaces. The hexagonal base allows secure wrench tightening (recommended torque: 1.2-1.8 N·m), while the 45° chamfered edges prevent tubing abrasion. Compatible with PU/Nylon tubing (ID 4mm recommended).
- Pneumatic cylinder port adapters in pick-and-place systems
- Vacuum generator line connections for automated packaging
- Tool changer interfaces on CNC machinery
- Modular pneumatic teaching setups in robotics labs
| Property | Property Value |
|---|---|
| sku | X-APH604 |
