Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW4M5
AirTAC X-APHW F-Type Threaded Rotatable Tee X-APHW4M5 Specifications
- Model: X-APHW4M5
- Type: F-type metric thread rotatable tee connector
- Thread standard: M5×0.8 (ISO 228-1 compliant)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Surface hardness: ≥HV200
- Pressure rating: 0.05-1.0 MPa (0.5-10 bar)
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (non-freezing)
- Fluid compatibility: Air, inert gases, vacuum
- Rotation angle: 360° continuous rotation
- Seal type: Integrated NBR O-ring (FDA compliant)
- Weight: 14.7±0.5g
- Dimensions: 24.5mm(L) × 17.8mm(W) × 17.8mm(H)
- Port configuration: 1 input + 2 outputs (T-shaped)
- Torque resistance: ≤2.5N·m tightening torque
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered three-way connector featuring tool-free rotational adjustment for flexible pneumatic circuit design. The electroplated brass construction provides excellent corrosion resistance in humid environments. Unique 45° chamfered ports prevent O-ring damage during tube insertion.
- Modular pneumatic test bench setups
- Robotic end-effector air distribution
- Dental chair pneumatic systems
- 3D printer compressed air networks
- Semiconductor cleanroom equipment
Installation note:
Apply thread sealant only on male threads (PTFE tape recommended).
For M5 connections, use 8-10mm tube insertion depth and secure with
M5 locknut (included). Rotate body before final tightening
to align ports.
Critical:
Not compatible with hydrocarbon-based lubricants. Maximum
50 assembly/disassembly cycles. Replace O-ring if torque
drops below 0.8N·m during maintenance.
| Property | Property Value |
|---|---|
| sku | X-APHW4M5 |
