Airtac X-APU Adapter - Straight Through X-APU10
$3.22
Regular price
$10.72
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APU10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APU10 Straight Through Fitting Technical Details
- Model: X-APU10
- Type: Straight through pneumatic quick connector
- Material: Polyamide (PA66) body, NBR seals
- Working pressure: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to +80℃
- Port size: M5×0.8 female thread (both ends)
- Flow rate: 450 L/min (at 0.5 MPa)
- Weight: 14g ±0.5g
- Dimensions: 30mm(L) × 16mm(W) × 16mm(H)
- Thread engagement depth: 7mm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Leakage: ≤0.1 NL/min (under 0.5 MPa)
- Certification: RoHS compliant
High-flow compact connector with 360° rotatable design, featuring dust-resistant push-to-connect mechanism. Optimized for vibration-prone environments with dual-locking safety grooves. Compatible with Φ4mm OD pneumatic tubing (4mm push-in).
Industrial Applications:
- Robotic end effector pneumatic circuits
- CNC machine tool air supply lines
- Plastic injection molding machine manifolds
- Semiconductor wafer handling equipment
- Food-grade air line connections (non-contact areas)
Installation protocol:
Apply 0.7-1.2N·m torque during assembly. Perform monthly seal integrity checks
in high-cycle applications (>10,000 actuations/day). Use tube inserts when
connecting to soft nylon tubing.
| Property | Property Value |
|---|---|
| sku | X-APU10 |
