Airtac X-APU Adapter - Straight Through X-APU14
$5.96
Regular price
$13.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APU14
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APU14 Straight Through Fitting Technical Details
- Model: X-APU14
- Type: Straight-through push-in pneumatic connector
- Port Thread: M5×0.8 (male) to M5×0.8 (female)
- Material: Nickel-plated brass (core)/PPS resin (housing)
- Operating Pressure: 0.05–1.0 MPa
- Temperature Range: -5℃ to 80℃
- Tube Compatibility: Ø4mm (OD) polyurethane/nylon tubing
- Seal Material: NBR (nitrile) rubber
- Thread Engagement: 6±1 turns for full sealing
- Vibration Resistance: ≤20 m/s² (ISO 10816-3)
- Weight: 18±2g
- Dimensions: 28mm(L) × 16mm(W) × 16mm(H)
- Certification: RoHS compliant
Bi-directional flow connector featuring tool-free installation with positive locking mechanism. The dual-stage O-ring design prevents air leakage under high cyclic loads. Nickel-plated internals resist corrosion from humid compressed air. Rated for 500,000+ connection cycles.
Common Applications:
- Modular pneumatic circuit branching in assembly lines
- Compact robotic end-effector air supply connections
- Medical device pneumatic control systems
- Food processing equipment (oil/moisture-resistant version available)
- 3D printer pneumatic extruder interfaces
Installation pro tip:
For optimal performance, cut tubing ends at 90°±2° using dedicated tube cutter.
Insert until hearing audible "click", then perform 2-3mm pull test to verify retention.
Pressure Note:
Requires derating to 0.7MPa max when used with silicone tubing.
Annual O-ring replacement recommended in continuous duty applications.
| Property | Property Value |
|---|---|
| sku | X-APU14 |
