Airtac X-APU Adapter - Straight Through X-APU4
AirTAC X-APU Series Straight Threaded Connector - X-APU4 Full Specifications
- Model: X-APU4
- Type: Straight-through pneumatic fitting (non-swivel)
- Thread standard: ISO 228 G1/8 (BSPP parallel)
- Material: PBT+GF (30% glass fiber reinforced)
- Seal type: Integrated O-ring (NBR material)
- Operating pressure: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Port-to-port length: 19.5±0.3mm
- Weight: 12.5g ±0.2g
- Dimensions: 19.5mm(L) × 16.5mm(W) × 16.5mm(H)
- Surface finish: Anti-corrosion plating (Zn-Ni alloy)
- Vibration resistance: 10-2000Hz, 5G acceleration
High-density molded connector with leak-proof design, featuring dual sealing surfaces for enhanced reliability in dynamic pressure conditions. The 45° tapered thread engagement ensures vibration resistance while maintaining low flow restriction (Kv factor: 0.45). Compatible with ISO 8434-1 pneumatic systems.
- Modular pneumatic manifold block assemblies
- Robotic end-effector tooling circuits
- Compressed air instrumentation lines
- Vacuum generator systems
- Medical gas handling equipment
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten - maximum torque 1.2N·m).
For vertical installations, use support brackets within 150mm intervals. Compatible with
tube OD: Ø4mm (1/8") push-to-connect systems.
| Property | Property Value |
|---|---|
| sku | X-APU4 |
