Airtac X-APU Adapter - Straight Through X-APU8
AirTAC X-APU Series Straight Through Fitting - X-APU8 Technical Details
- Model: X-APU8
- Type: Straight through push-in pneumatic connector
- Thread standard: PT1/8 (BSPP)
- Material: Brass (nickel-plated) with PBT housing
- Seal material: NBR (nitrile rubber)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Tube compatibility: Ø4mm (5/32") or Ø6mm (1/4") OD pneumatic tubing
- Max flow rate: 300 L/min (at 0.5 MPa)
- Leakage rate: ≤3 bubbles/min (ISO 6952 test)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40
- Weight: 65g ±2g
- Dimensions: 30mm(L) × 18mm(W) × 18mm(H)
Dual-purpose connector featuring tool-free tube installation with positive locking mechanism. The 360° rotatable design enables flexible piping layouts while maintaining leak-proof performance. Nickel-plated brass construction resists oxidation and chemical corrosion in humid environments.
- Modular pneumatic system interconnections
- Branch line distribution in automation equipment
- Compressed air networks for semiconductor manufacturing
- Packaging machinery air line extensions
- Medical device pneumatic circuit junctions
- Food-grade air supply systems (when using compatible tubing)
Installation protocol:
Manually tighten to 12-15 N·m torque range. Avoid overtightening which may deform sealing surfaces.
For gas applications, apply PTFE tape to male threads. Always insert tubes perpendicular to fitting axis.
| Property | Property Value |
|---|---|
| sku | X-APU8 |
