Airtac X-EPKD Adapter - Reducing Thread Manifold X-EPKD10803
AirTAC X-EPKD Reducing Thread Five-Way Fitting X-EPKD10803 Technical Details
- Model: X-EPKD10803
- Type: ISO G-thread reducing manifold (5 ports)
- Material: Aluminum alloy ADC12 with nickel plating
- Main thread: G1/8 (ISO228 standard)
- Reduced thread: M5×0.8 (4 ports)
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃
- Weight: 82±3g
- Dimensions: 44mm(L) × 34mm(W) × 26mm(H)
- Surface roughness: Ra ≤3.2μm
- Seal compatibility: Compatible with NBR/PU pneumatic seals
- Vibration resistance: ≤10Hz/1.5mm amplitude
- Certification: RoHS compliant
High-density pneumatic distribution block designed for space-constrained installations. Features precision-machined flow channels with 30% reduced pressure drop compared to standard manifolds. Anodized finish prevents galling during threaded connections. Includes integrated O-ring grooves for leak-free assembly.
- Modular pneumatic control cabinets
- Robotic end-effector tooling manifolds
- CNC machine pneumatic distribution nodes
- Semiconductor handling equipment
- Multi-axis actuator synchronization systems
Installation guidance:
Apply thread sealant only on male threads (PTFE tape recommended).
Tightening torque: 12-15N·m for G1/8 ports, 2-3N·m for M5 ports.
Avoid overtightening reduced ports - use calibrated torque wrench.
| Property | Property Value |
|---|---|
| sku | X-EPKD10803 |
